Scale Grid graph paper

Pre-scaled architectural and engineering grids let you draw in real-world units directly on the page. Pick the ratio that matches the drawing - 1:50 for residential plans, 1:100 for whole buildings, 1:200 for site layouts, 1:500 for master plans. Background: A reading list on technical-drawing standards.
